    MiniGran

    €1

    MiniGran is a laboratory granulator designed for granulation of smaller plastic parts. Thanks to its compact dimensions, this granulator can be placed almost anywhere and is therefore very suitable for laboratory applications. The granulator is suitable for all types of plastics, thanks to the low speed of the rotor, plastic materials are processed into high-quality recyclate with low dust.

    Detailed information

    Device Calibration
    Device Calibration
    ISO1133-1 ISO1133-2
    Comprehensive Support
    Comprehensive Support
    Including Assistance
    Over 30 Years in the Market
    Over 30 Years in the Market
    Throughout Eastern Europe
    Service within 48 hours
    Service within 48 hours
    from reporting the fault

    Product detailed description

    Technical data


    Openable cutting chamber: 80mm x 100mm
    Rotor diameter: 90mm
    Rotor speed: 112 U/min
    Rotor blades: 9 pcs.
    Stator blades: 2 pcs.
    Motor power:< /strong> 0.75 kW
    Power supply: 230, 400, or 480 V / 50 Hz
    Sieve hole size: 3-5 mm
    Sieve: Standard with 4 mm holes, alter.
    3 and 5 mm holes (specify when ordering)
    Weight: About 40 kg
